Introduction

Communication Protocol(s) Conventions

Field Parameters Conventions

API - Messages Format Specification

General Message Format
Irrespective of the communication channel, ether HTTP(s) or WSS, each send/received message has the respective wrapper fields/values around it. Such fields are used to ensure the proper sequencing between clients and gateways. Below is the representations of respective wrappers:

Request Wrapper (GET)
There is a set of the public API requests that can be only done via the HTTP(s) GET calls. For such requests there’s no body wrapper structure and all the required dedicated request parameters are set in the URL as respective parameters

Request Wrapper (POST and WSS)

Request warpper example for POST Message

Copy to Clipboard
{
    "request_id": "b1ea627c-8288-4489-b0c0-d2eba01ca96c",
    "method": "private/place-order",
    "api_key": "abc0",
    "params": {
        "price": "1015979000",
        "side": "BUY",
        "size": "0.001",
        "symbol": "BTC-IDR",
        "time_in_force": "GTC",
        "type": "LIMIT"
    },
    "timestamp": 1719292078182,
    "signature": "53129569a2f541975bd6dd68b6608b4a0f318cc77948c012bc1994ff5276f014"
}

Private requests can be sent either via POST HTTP call to respective API endpoint or via WebSocket. The message format is the same for both HTTP and WSS endpoints. Each request contains:

Field Type Required Description
request_id string no ID of a request (preferably UUID). Generated by the client. The gateway will use the same id in the response so client can match request/response on its end.

In case if the field is not set, the gateway will use same value as timestamp field as request_id
timestamp integer yes timestamp(unix milli) of when the request is sent.

NOTE: the timestamp should be within an acceptable range and client’s clock should be at least in NTP sync. If timestamp is more than 10 seconds older or 1 second in the future compared to server time, such request will be rejected.
api_key string yes API key of a client
signature string depends hashed value consisting of data (including timestamp) that is signed using SHA256 along with client’s API secret.

Should be always set in case of the POST call. In case is the WSS call is ignored (but WSS should authenticate itself with the respective authentication call)
method string (enum) yes method of the APIs (place-order, list-orders, cancel-order, list-trades)
params object yes payload that will be processed

Response Wrapper

Response returned by the exchange follows the format defined in the table below.

Success response example

Copy to Clipboard
{
  "request_id": "a498b06a-5e0b-469a-84c2-3ab27d301633",
  "timestamp": 1719304915127,
  "method": "private/place-order-list",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "results": [
      {
        "index": 0,
        "code": 0,
        "message": "SUCCESS",
        "reason": "",
        "order_id": "e1d90562-1b70-4c93-b25a-be8d485ea9a9",
        "client_order_id": "31f767cb-d826-4bef-b799-f6f9cdf2c11f"
      }
    ]
  }
}

Error Response Example

Copy to Clipboard
{
  "request_id": "364b73b6-5d3a-43c0-b48c-eee4766811f8",
  "timestamp": 1719304987707,
  "method": "private/cancel-order-list",
  "code": 4,
  "message": "FAILED",
  "reason": "all orders failed to be canceled",
  "data": {
    "results": [
      {
        "index": 0,
        "code": 7,
        "message": "ORDER_NOT_FOUND"
      },
      {
        "index": 1,
        "code": 7,
        "message": "ORDER_NOT_FOUND"
      }
    ]
  }
}
Field Type Description
request_id string ID of a client request (as set by the client)
timestamp integer timestamp(unix milli) of when the response is sent
method string (enum) method that was invoked by the client
channel string name of the channel for the subscription stream, see Data Stream for details.
NOTE: only is set when method is set to “subscription”
code integer code related to the response status, see API Response Code Mapping for details
message string (enum) message description related to the response status
reason string text description of the error code/message for debugging and analysis purposes
NOTE: will only be set/sent in case of non-successful response
data object data of the response

API - Signature Computation

We are usuing the HMAC-SHA256 signature calculation based on API Secret.

  1. To compute the signature, client should first create a data_string by serializing the request params in a specific way:
    • The params object should be sorted based on key in ascending order
    • The sorted object should be converted to the string (called data_string below) via combining keys and values one by one without any separators
    • For example "params": {"name": "Harry", "active": false, "age": 11} will give data_string value activefalseage11nameHarry*
    • When params object is empty, null or absent it is represented by an empty string
  2. Then the signature is calculated as HMAC-SHA256 using API Secret as a key and payload as a concatenation result of request_id + timestamp + method + api_key + data_string. Bytes returned by HMAC-SHA256 are encoded as a hexadecimal string.
  3. Computed HMAC hexadecimal string is added to the request wrapper payload as the signature field.

For example given api key "abc0" and secret "abc" a valid signed place-order request would be:

Copy to Clipboard
{
  "request_id": "fc9f3e2e-6791-49ac-af23-715fccac13dd",
  "method": "private/place-order",
  "api_key": "abc0",
  "params": {
    "price": "1015979000",
    "side": "BUY",
    "size": "0.001",
    "symbol": "BTC-IDR",
    "time_in_force": "GTC",
    "type": "LIMIT"
  },
  "timestamp": 1719295943513,
  "signature": "2094afd679b8a8afe1a74350aa5a3f05329309ce48ac9a4f05e28750be2c4ed4"
}

For this request the string to sign is "fc9f3e2e-6791-49ac-af23-715fccac13dd1719295943513private/place-orderabc0price1015979000sideBUYsize0.001symbolBTC-IDRtime_in_forceGTCtypeLIMIT".

API - Response Codes Mapping

Internal Code (Current) HTTP status Message Reason (description) Developer Notes
17 429 TOO_MANY_REQUESTS See API - Rate Limits
0 200 SUCCESS executed successfully, no issues “empty reason”
1 200 BAD_SYMBOL - Unsupported Symbol - Not found in reference data
2 400 BAD_REQUEST Withdrawal:
- Address not whitelisted
- Invalid network
- Invalid amount (Must be a number)
- Amount must be greater than 0
- Amount must be greater than minimum withdrawal fee
- Duplicate request ID
- Invalid asset
Spot:
- empty symbol
- page should be more than or equal to 0
- page size should be 1 to 200
- empty order ID and client order ID
- TEnd should be greater than TStart
- TStart and TEnd should be within 24 hours
- symbol or tradeIds is required
- both TStart and TEnd should be specified
3 200 ORDER_REJECTED - price is not divisible by price_tick_size
- size is not divisible by quantity_tick_size
- order value above maximum
- order value below minimum
- exceeding maximum order size
- below minimum order size
- sell price should be within the band
- buy price should be within the band
4 200 FAILED all orders failed to be cancelled
5 200 PARTIAL_SUCCESS failed to place all orders
7 200 ORDER_NOT_FOUND Order not found
8 500 INTERNAL_ERROR
9 - HEARTBEAT_TIMEOUT client did not respond to heartbeat, closing connection
10 200 INSUFFICIENT_BALANCE insufficient balance
11 400 TIMESTAMP_EXPIRED the timestamp sent in the request is out of sync with the server timestamp
12 400 INVALID_METHOD
10 INSUFFICIENT_BALANCE didn’t reach minimum amount

API - WebSocket Channels Subscription

Channels Subscription

Websocket connections allow for subscriptions to streaming data over the dedicated channel. For this, there’s a dedicated subscribe method available as part of the request wrapper:

Field Type Required Description
channels array of strings yes name of the respective channel to which we need to subscribe to or unsubscribe from

Example subscription request:

Copy to Clipboard
{
  "request_id": "0331f39d-a300-4b94-a015-f75a9aba8cea",
  "timestamp": 1719305357836,
  "method": "subscribe",
  "params": {
    "channels": [
      "trades.SOL-IDRT",
      "aggrbook.snapshot.10.SOL-IDRT"
    ]
  }
}

Successful Subscription response (in case of multiple channels):

Copy to Clipboard
{
  "request_id": "d19b92b1-cbfb-4e4e-a7da-74772389a4b1",
  "timestamp": 1719310184345,
  "method": "subscribe",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "channel": "trades.SOL-IDR"
  }
}

{
  "request_id": "d19b92b1-cbfb-4e4e-a7da-74772389a4b1",
  "timestamp": 1719310184345,
  "method": "subscribe",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "channel": "aggrbook.snapshot.10.SOL-IDR"
  }
}

Error Subscription response:

Copy to Clipboard
{
  "request_id": "c74938d1-c128-498b-8107-8712c31a4b9e",
  "timestamp": 1719305584322,
  "method": "subscribe",
  "code": 2,
  "message": "BAD_REQUEST",
  "reason": "unknown channel name",
  "data": {
    "channel": "nonexistent"
  }
}

Channels to subscribe can be both public and private. In case of the private channel the Websocket Channels Subscription routine should be performed first.
One subscription message can contain an array of channels to subscribe to. The subscription replies will be one per requested channel.

Public channels:

Channel Name Description
aggrbook.snapshot.{num_levels}.{symbol} aggregated book snapshot for {num_levels} levels of symbol {symbol}
trades.{symbol} trades happened in the matching engine for symbol {symbol}

Private channels:

Channel Name Description
user.orders.{symbol} statuses updates for all orders sent for a given symbol {symbol}
user.orders statuses updates for all order for all symbols
user.trades.{symbol} trades/fills notifications for a given symbol {symbol}
user.trades trades/fills notification for all symbols
user.balance.snapshot periodic updates of user’s account balance

The response for the channel subscription comes in the form of Generic Response Wrapper (both success and error), with the following addition:
- there’s additional channel field sent back with the name of the channel the message belongs to, it’s a part of data field and is always sent.

Channel Unsubscription

You can unsubscribe from the required channel at any point in time. For this you can use the similar Subscription request wrapper, but with “method”: “unsubscribe” field. Response structure is similar as subscription response.

Channel Data Stream

In case the subscription to the channel is successful and the respective return code is returned, gateway will start streaming the data to the client. The stream message has the following fields:

Field Type Description
timestamp integer gateway timestamp(unix milli) when the message was sent to the client
method string always “subscription” to show that the message is the channel data message
channels string the actual name of the channel the update is sent for
data object subscription stream message payload data object

Channel Data Stream Errors

In case any unrecoverable application or the protocol error is encountered during the subscription streaming process, the gateway will close the web-socket with the respective Close Frame specifying the closure status code.

Heartbeats

In order to ensure the client’s liveness, the backend gateway may from time to time send the respective heartbeat request to which client needs to send the response within 10 seconds from time frame from the value specified in request.

Failure to reply to heartbeat request within the given time frame will result in server terminating the websocket connection.

Example of heartbeat request message:

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 1676869976772,
  "method": "heartbeat-request"
}

Example of heartbeat response message:

Copy to Clipboard
  {
    "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
    "timestamp": 1676869978800,
    "method": "heartbeat-response"
  }

request_id in the response has to match the one in request.

API - Rate Limits

Our API uses a weighted rate limiting strategy where each account has X number of tokens every second and each endpoint, e , has a different cost, Ce . And the following limit will be enforced every window of a second.

sum(Ce*Ne) <= X

where Ne is the number of calls made on endpoint e in that window of a second.

Response

When rate limit is exceeded, expect to receive code=17 in the response message and message=TOO_MANY_REQUESTS.

Copy to Clipboard
{
        "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
    "timestamp": 1672304484978,
        "method": "public/get-book",
        "code": 17,
        "message": "TOO_MANY_REQUESTS",
}

Default Limits

Account Type Tokens Per Second
Market Maker 50000

Costs

Method Cost Assigned
public/get-book 500
public/get-symbols-reference 100
public/get-trades 100
public/get-network-reference 200
public/get-candlesticks 300
public/get-ticker 100
public/trading-fees-and-limits 500
public/exchange-status 100
private/place-order 1000
private/place-order-list 1500
private/cancel-order 1000
private/cancel-order-list 1250
private/cancel-all-orders 1250
private/get-open-orders 100
private/get-order-details 300
private/get-order-history 1000
private/get-trade-history 1000
private/get-account-information 100
private/get-funds-transfer-history 1000
private/get-withdrawal-status 1000
private/create-withdrawal 1000
private/confirm-withdrawal 2000
private/get-deposit-addresses 1000

Public API

Websocket Authentication

Example websocket "public/auth" request:

Copy to Clipboard
{
  "request_id": "837873eb-0d68-457b-860f-a853046455cf",
  "timestamp": 1719306245083,
  "method": "public/auth",
  "api_key": "abc0",
  "signature": "6d13d543b959454eb6b05ac5d3722aad3d9cd7a887d5083fb1818d18e34cff36"
}

Example response:

Copy to Clipboard
{
  "request_id": "837873eb-0d68-457b-860f-a853046455cf",
  "timestamp": 1719306245342,
  "method": "public/auth",
  "code": 0,
  "message": "SUCCESS",
  "data": null
}

Authentication call should be done before any private WSS method call or private WSS subscription is done over the established websocket session. If not done in such order, every private API request will be rejected.

Authentication request is a simple signed request wrapper without a params field.

In case of successful authentication, the response wrapper with code = 0 value will be returned, meaning that the connection is authorized for listening to private channels or executing private requests without providing api_key and signature on the upcoming requests messages during this websocket session.

Get Book

GET /v1/public/get-book?symbol=DOGE-IDR&depth=1

Copy to Clipboard
{
  "timestamp": 1719306524062,
  "method": "public/get-book",
  "code": 0,
  "message": "OK",
  "data": {
    "symbol": "DOGE-IDR",
    "bids": [
      [
        "2018",
        "58290.1",
        "1"
      ]
    ],
    "asks": [
      [
        "2021",
        "58295",
        "1"
      ]
    ]
  }
}

Retrieves the latest snapshot of orderbook for a given instrument.

HTTP & Websocket Request

Protocol Body
HTTP GET /v1/public/get-book?symbol=BTC-IDR&depth=10
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "public/get-book",
"params": {
"symbol": "BTC-IDR",
"depth": 10
}
}

Request Parameters

Field Type Required Description
symbol string yes Symbol name
depth integer no The depth (number of price levels) of the market data book. Default is 1 for level 1 order book (quotes). Valid values are 1 or 10.

Response Parameters - Body:

Field Type Description
data.symbol string Symbol name
data.bids array (string) Price levels ordered by descending by price. Each price level is three elements array of decimals. Bids array: [0] = Price, [1] = Quantity, [2] = Number of Orders
data.asks array (string) Price levels ordered by descending by price. Each price level is three elements array of decimals. Bids array: [0] = Price, [1] = Quantity, [2] = Number of Orders

Get Symbol Reference

GET /v1/public/get-symbols-reference

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 1672304484978,
  "method": "public/get-symbols-reference",
  "code": 0,
  "message": "SUCCESS",
  "reason": "",
  "data": {
    "symbols": [
      {
        "symbol": "BTC-USDT",
        "quote_asset": "USDT",
        "base_asset": "BTC",
        "price_decimals": 7,
        "size_decimals": 0,
        "max_size": "1000000000",
        "min_size": "10",
        "max_value": "85000000",
        "min_value": "10000",
        "max_price": "1000",
        "min_price": "0.0000001",
        "quantity_tick_size": "10",
        "price_tick_size": "0.0000001",
        "last_updated_at": 1666261193053
      },
      {
        "symbol": "ETH-USDT",
        "quote_asset": "USDT",
        "base_asset": "ETH",
        "price_decimals": 7,
        "size_decimals": 0,
        "max_size": "1000000000",
        "min_size": "10",
        "max_value": "85000000",
        "min_value": "10000",
        "max_price": "1000",
        "min_price": "0.0000001",
        "quantity_tick_size": "10",
        "price_tick_size": "0.0000001",
        "last_updated_at": 1666261193053
      }
    ]
  }
}

Retrieves the reference data details for the instruments listed on Pro.

HTTP & Websocket Request

Protocol Body
HTTP GET /v1/public/get-symbols-reference
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "public/get-symbols-reference",
"params": {}
}

Response Parameters - Body:

Field Type Description
data.symbol string An array of symbols
data.symbols[index].symbol string e.g. BTC-USDT
data.symbols[index].base_asset string e.g. BTC
data.symbols[index].quote_asset string e.g. USDT
data.symbols[index].price_decimals integer Maximum decimal places for specifying price
data.symbols[index].size_decimals integer Maximum decimal places for specifying size
data.symbols[index].max_size string Maximum size
data.symbols[index].min_size string Minimum size
data.symbols[index].max_value string Maximum value in quote
data.symbols[index].min_value string Minimum value in quote
data.symbols[index].max_price string Maximum price
data.symbols[index].min_price string Minimum price
data.symbols[index].quantity_tick_size string Quantity tick size
data.symbols[index].price_tick_size string Price tick size
data.symbols[index].last_updated_at integer Instrument last update time (Unix timestamp)

Get Trades

GET /v1/public/get-trades?symbol=WIF-IDR

Copy to Clipboard
{
    "timestamp": 1719307521557,
    "method": "public/get-trades",
    "code": 0,
    "message": "OK",
    "data": {
        "trades": [
    {
        "side": "SELL",
        "price": "30663",
        "size": "0.32",
        "timestamp": 1719307508796,
        "symbol": "WIF-IDR"
    },
    {
        "side": "BUY",
        "price": "30694",
        "size": "0.32",
        "timestamp": 1719307494778,
        "symbol": "WIF-IDR"
    },
    {
        "side": "SELL",
        "price": "30649",
        "size": "0.32",
        "timestamp": 1719307478759,
        "symbol": "WIF-IDR"
    }
        ]
    }
}

Retrieves the Public Trades information (public information about the orders filled). A max fixed number of the latest trades is returned.

HTTP & Websocket Request

Protocol Body
HTTP GET /v1/public/get-trades?symbol=WIF-IDR
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 1719307478759
"method": "public/get-trades",
"params": {
"symbol": "WIF-IDR"
}
}

Request Parameters

Field Type Description
symbol string Symbol name

Response Parameters - Body:

Field Type Description
trades[index].side string Side of the taker order (buy or sell)
trades[index].price string Trade price
trades[index].size string Trade quantity
trades[index].timestamp integer Trade timestamp
trades[index].symbol string Symbol name

Trading Private API (Authentication Required)

Place Order

Place order request example

Copy to Clipboard
{
  "request_id": "fc9f3e2e-6791-49ac-af23-715fccac13dd",
  "method": "private/place-order",
  "api_key": "abc0",
  "params": {
    "price": "1015979000",
    "side": "BUY",
    "size": "0.001",
    "symbol": "BTC-IDR",
    "time_in_force": "GTC",
    "type": "LIMIT"
  },
  "timestamp": 1719295943513,
  "signature": "2094afd679b8a8afe1a74350aa5a3f05329309ce48ac9a4f05e28750be2c4ed4"
}

Place order success response example

Copy to Clipboard
{
  "request_id": "28fca426-3d70-4f27-9171-4ef62cb3ae42",
  "timestamp": 1719289547020,
  "method": "private/place-order",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "order_id": "0a6cd728-31c9-49e4-be86-9d74a7976440",
    "client_order_id": "99a230b8-8073-44ee-89f8-272dd8a37ed8"
  }
}

Place order rejected response

Copy to Clipboard
{
  "request_id": "68861317-b13a-4bf2-ba71-b74f9d0b4b23",
  "timestamp": 1719307871325,
  "method": "private/place-order",
  "code": 3,
  "message": "ORDER_REJECTED",
  "reason": "exceeding maximum order size 0.5",
  "data": {
    "order_id": "",
    "client_order_id": ""
  }
}

The client is kindly requested to provide a unique client_order_id. Our trading system solely verifies the uniqueness of the client order ID against the user's existing active orders. Consequently, it is possible for the client to submit two orders with the same client_order_id, provided that the orders' lifecycles do not intersect with each other.

The place order request reply only confirms whether the order passed all the validity checks, being assigned its unique order_id and is enroute to the orderbook. To check whether the order’s actual status the historical information should be checked, or WSS subscription to user.orders channel should be made to listen for order status updates.

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/place-order
Limit Order
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-key",
"signature": "my-signature",
"method": "private/place-order",
"params": {
"symbol": "BTC-IDR",
"side": "BUY",
"type": "LIMIT",
"price": "350000000",
"size": "1.005",
"client_order_id": "my-client-order-id-1",
"time_in_force": "GTC",
"exec_inst": "POST_ONLY",
}
}
Websocket Market Order
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-key",
"signature": "my-signature",
"method": "private/place-order",
"params": {
"symbol": "BTC-IDR",
"side": "BUY",
"type": "MARKET",
"notional": "1000000",
"client_order_id": "my-client-order-id-1"
}
}

Request Parameters

Field Type Required Description
symbol string yes Symbol the order is to be place for
side enum(string) yes BUY or SELL
type enum(string) yes order type, currently supported types are: MARKET, LIMIT
price string depends For LIMIT order type only: price the order is expected to be executed
size string depends For LIMIT and MARKET orders: qty to be either bought or sold
NOTE: will be ignored in case notional is set for MARKET (BUY) order
notional string depends For MARKET (BUY) order only: amount to spend
client_order_id string no clients unique identified for this order
time_in_force string depends For LIMIT order type only: order lifetime params, options are (IOC,FOK,GTC)
exec_inst string depends For LIMIT order type only: order execution instructions, options are (empty,POST_ONLY)

Response Parameters - Body:

Field Type Description
data.order_id string (uidv4) unique order identifier assigned by Exchange in case order passed all the checked and is routed to the respective matching engine
data.client_order_id string assigned by client custom id that should be returned together with the order status updates later. Should be unique during one full trading day
NOTE: if not provided by the client, will contain same value as timestamps. Yet, clients are encouraged to use client_order_id explicitly

Place Order List

Place order list response example

Copy to Clipboard
{
  "request_id": "603cffcf-79d2-4c53-a66f-d3008d487716",
  "timestamp": 1719308208488,
  "method": "private/place-order-list",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "results": [
      {
        "index": 0,
        "code": 0,
        "message": "SUCCESS",
        "reason": "",
        "order_id": "998271f3-0a0c-4f3f-becc-d31e0837f458",
        "client_order_id": "8af646e9-7ec1-4508-a2c8-201ad10126c3"
      },
      {
        "index": 1,
        "code": 0,
        "message": "SUCCESS",
        "reason": "",
        "order_id": "d816983d-b8ae-4f46-a5a7-75c767a20433",
        "client_order_id": "a9486476-1d05-4961-b410-cf3bebc16b06"
      }
    ]
  }
}

Partial Rejected Place Order List response example

Copy to Clipboard
{
  "request_id": "c34795b2-d793-4a01-aa5a-a32195d759e7",
  "timestamp": 1718808872662,
  "method": "private/place-order-list",
  "code": 5,
  "message": "PARTIAL_SUCCESS",
  "reason": "failed to place some orders",
  "data": {
    "results": [
      {
        "index": 0,
        "code": 3,
        "message": "ORDER_REJECTED",
        "reason": "buy price should be within the band 7500-22500",
        "order_id": "",
        "client_order_id": "de392715-d105-499d-9d40-401d618ead61"
      },
      {
        "index": 1,
        "code": 0,
        "message": "SUCCESS",
        "reason": "",
        "order_id": "12b81ba3-4eb4-4dff-bfcd-f6142f5632a6",
        "client_order_id": "c8ab10ce-4993-4c6d-ad97-19cb6eedac5d"
      }
    ]
  }
}

Request that is able to place a number of orders by utilizing a single API call.

The client is kindly requested to provide a unique client_order_id. Our trading system solely verifies the uniqueness of the client order ID against the user's existing active orders. Consequently, it is possible for the client to submit two orders with the same client_order_id, provided that the orders' lifecycles do not intersect with each other.

The place order request reply only confirms whether the order passed all the validity checks, being assigned it’s unique Exchange side order_id and is enroute to the orderbook. To check whether the order’s actual status the historical information should be checked, or WSS subscription to user.orders channel should be made for listen for updates.

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/place-order-list
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"api_key": "my-api-key",
"signature": "my-signature",
"timestamp": 16775774797462,
"method": "private/place-order-list",
"params": {
"orders": [
{
"symbol": "BTC-IDR",
"side": "BUY",
"type": "LIMIT",
"price": "350000000",
"size": "1.005",
"client_order_id": "my-client-order-id-1",
"time_in_force": "GTC",
"exec_inst": "POST_ONLY",
},
{
"symbol": "BTC-IDR",
"side": "BUY",
"type": "MARKET",
"notional": "1000000",
"client_order_id": "my-client-order-id-2"
},
...
]
}
}
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/place-order-list",
"params": {
"orders": [
{
"symbol": "BTC-IDR",
"side": "BUY",
"type": "LIMIT",
"price": "350000000",
"size": "1.005",
"client_order_id": "my-client-order-id-1",
"time_in_force": "GTC",
"exec_inst": "POST_ONLY",
},
{
"symbol": "BTC-IDR",
"side": "BUY",
"type": "MARKET",
"notional": "1000000",
"client_order_id": "my-client-order-id-2"
},
...
]
}
}

Request Parameters

Field Type Required Description
orders array(object) yes array of the order records to be places. Max 10 elements
Each record follows the parameters schema described below
symbol string yes Symbol the order is to be place for
side enum(string) yes BUY or SELL
type enum(string) yes order type, currently supported types are: MARKET, LIMIT
price string depends For LIMIT order type only: price the order is expected to be executed
size string depends For LIMIT and MARKET orders: qty to be either bought or sold
NOTE: will be ignored in case notional is set for MARKET (BUY) order
notional string depends For MARKET (BUY) order only: amount to spend
client_order_id string no clients unique identified for this order
time_in_force string depends For LIMIT order type only: order lifetime params, options are (IOC,FOK,GTC)
exec_inst string depends For LIMIT order type only: order execution instructions, options are (empty,POST_ONLY)

Request Parameters - Response Body:

Field Type Required Description
data.results string yes result array where each index represents the object that contains the result of the orders list placement. Below are the object fields:
data.results.[index].index integer yes index of the element in request array
data.results.[index].code integer yes new order placement execution code
data.results.[index].message string yes new order placement execution message code
data.results.[index].reason string depends in case new order placement placement is rejected, reason of the rejection
data.results.[index].client_order_id string yes assigned by client custom id that should be returned together with the order status updates later. Should be unique during one full trading day
NOTE: if not provided by the client, will contain same value as timestamps. Yet, clients are encouraged to use client_order_id explicitly
data.results.[index].order_id string (uidv4) depends unique order identifier assigned by Exchange in case order passed all the checked and is routed to the respective matching engine

Cancel All Orders

Success response

Copy to Clipboard
{
  "request_id": "66959af9-7d6e-446a-8394-e458b58aecea",
  "timestamp": 1719240172638,
  "method": "private/cancel-all-orders",
  "code": 0,
  "message": "SUCCESS"
}

Rejected response example

Copy to Clipboard
{
  "request_id": "66959af9-7d6e-446a-8394-e458b58aecea",
  "timestamp": 1719245275196,
  "method": "private/cancel-all-orders",
  "code": 1,
  "message": "BAD_SYMBOL",
  "reason": "unsupported symbol"
}

The cancel all orders request reply only confirms whether the cancellation instruction is successfully placed. To check whether the orders are actually cancelled or not, detailed order historical information should be checked, or WSS subscription to user.orders channel should be made for listen for updates.

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/cancel-all-orders
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"api_key": "my-api-key",
"signature": "my-signature",
"timestamp": 16775774797462,
"method": "private/cancel-all-orders",
"params": {
"symbol": "BTC-IDR"
}
}
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/cancel-all-orders",
"params": {
"symbol": "BTC-IDR"
}
}

Request Parameters

Field Type Required Description
symbol string yes symbol for which all orders should be cancelled

Cancel Order

Success response example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 16775774798300,
  "method": "private/cancel-order",
  "code": 0,
  "message": "SUCCESS"
}

Rejected response example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 1718713055526,
  "method": "private/cancel-order",
  "code": 7,
  "message": "ORDER_NOT_FOUND"
}

The cancel order request reply only confirms whether the cancellation is successfully placed. To check whether the order is actually cancelled or not, detailed order historical information should be checked, or WSS subscription to user.orders channel should be made for listen for updates.

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/cancel-order
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"api_key": "my-api-key",
"signature": "my-signature",
"timestamp": 16775774797462,
"method": "private/cancel-order",
"params": {
"symbol": "BTC-IDR",
"order_id": "abcdefg-123-abcd-1234-c6ff6de212e2"
}
}
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/cancel-order",
"params": {
"symbol": "BTC-IDR",
"order_id": "abcdefg-123-abcd-1234-c6ff6de212e2"
}
}

Request Parameters

Field Type Required Description
symbol string yes symbol for which the order should be cancelled
order_id string yes exchange generated ID when the order was placed

Cancel Order List

Success response example

Copy to Clipboard
{
  "request_id": "4ca9dca1-c8a1-4684-82f5-a02df8ee7241",
  "timestamp": 1719308888747,
  "method": "private/cancel-order-list",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "results": [
      {
        "index": 0,
        "code": 0,
        "message": "SUCCESS"
      },
      {
        "index": 1,
        "code": 0,
        "message": "SUCCESS"
      },
      {
        "index": 2,
        "code": 0,
        "message": "SUCCESS"
      },
      {
        "index": 3,
        "code": 0,
        "message": "SUCCESS"
      },
      {
        "index": 4,
        "code": 0,
        "message": "SUCCESS"
      }
    ]
  }
}

Partial success example

Copy to Clipboard
{
  "request_id": "ea80dd7f-354e-45a7-a828-0b91f3b38749",
  "timestamp": 1719308723061,
  "method": "private/cancel-order-list",
  "code": 5,
  "message": "PARTIAL_SUCCESS",
  "reason": "some orders failed to be canceled",
  "data": {
    "results": [
      {
        "index": 0,
        "code": 0,
        "message": "SUCCESS"
      },
      {
        "index": 1,
        "code": 0,
        "message": "SUCCESS"
      },
      {
        "index": 2,
        "code": 0,
        "message": "SUCCESS"
      },
      {
        "index": 3,
        "code": 0,
        "message": "SUCCESS"
      },
      {
        "index": 4,
        "code": 7,
        "message": "ORDER_NOT_FOUND"
      },
      {
        "index": 5,
        "code": 0,
        "message": "SUCCESS"
      }
    ]
  }
}

The cancel order request reply only confirms whether the cancellation is successfully placed. To check whether the order is actually cancelled or not, detailed order historical information should be checked, or WSS subscription to user.orders channel should be made for listen for updates.

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/cancel-order-list
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"api_key": "my-api-key",
"signature": "my-signature",
"timestamp": 16775774797462,
"method": "private/cancel-order-list",
"params": {
"orders": [
{
"symbol": "BTC-IDR",
"order_id": "abcdefg-123-abcd-1234-c6ff6de212e2"
},
{
"symbol": "BTC-USDTT",
"order_id": "xyzasdf-456-efgh-5678-c6ff6de211k3"
},
...
]
}
}
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/cancel-order-list",
"params": {
"orders": [
{
"symbol": "BTC-IDR",
"order_id": "abcdefg-123-abcd-1234-c6ff6de212e2"
},
{
"symbol": "BTC-USDTT",
"order_id": "xyzasdf-456-efgh-5678-c6ff6de211k3"
},
...
]
}
}

Request Parameters

Field Type Required Description
orders array(object) yes array of the orders records to be cancelled. Max 10 elements. Each record follows the parameters schema described here

Response Parameters - Body:

Field Type Required Description
data.results 2d-array (object) yes result array where each index represents the object that contains the result of the cancellation placement. Below are the object fields
data.results[index].index integer yes index of the element in request array
data.results[index].code integer yes cancellation placement execution code
data.results[index].message string(enum) yes cancellation placement execution message code
data.results[index].reason string no in case cancellation placement is rejected, reason of the rejection

Get Account Information

Response example

Copy to Clipboard
{
    "request_id": "35061da9-6343-4c72-ac20-b228a1456623",
    "timestamp": 1719310184322,
    "method": "private/get-account-information",
    "code": 0,
    "message": "SUCCESS",
    "data": {
        "assets": {
    "IDR": {
        "balance": "100000000000",
        "available": "100000000000",
        "order": "0",
        "notional": {
    "available": "100000000000",
    "total": "100000000000",
    "currency": "IDR"
        }
    },
    "PTU": {
        "balance": "100000000000",
        "available": "100000000000",
        "order": "0",
        "notional": {
    "available": "100000000000",
    "total": "100000000000",
    "currency": "IDR"
        }
    }
        }
    }
}

Returns the actual state of the balance for the account that is authorized by respective api_key.

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/get-account-information
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"api_key": "my-api-key",
"signature": "my-signature",
"timestamp": 16775774797462,
"method": "private/get-account-information",
"params": {}
}
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/get-account-information",
"params": {}
}

Response Parameters - Body:

Field Type Description
assets object List of all non-zero assets in the wallet in dictionaries. The keys of the dict is the asset name such as "eth", "btc"
assets.[asset_name].balance string Total balance of current asset
assets.[asset_name].available string Available amount to withdraw of current asset
assets.[asset_name].order string Total balance of open orders

Get Open Orders

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 16775774798300,
  "method": "private/get-open-orders",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "count": 345,
    "orders": [
      {
        "status": "PARTIALLY_FILLED",
        "symbol": "BTC-IDR",
        "type": "LIMIT",
        "time_in_force": "GTC",
        "exec_inst": "POST_ONLY",
        "side": "BUY",
        "price": "15000",
        "size": "2",
        "cum_price": "15000",
        "cum_size": "0.35",
        "cum_value": "5250",
        "order_id": "12345678-abcd-efgh-ijkl-1234567890ab",
        "client_order_id": "my-order-id-1",
        "created_at": 16775774795300,
        "updated_at": 16775774797678
      },
      ...
    ]
  }
}

Request the actual status of the order that were is expected to be placed within the last trading day session (within the last 24 hours).

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/get-open-orders
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"api_key": "my-api-key",
"signature": "my-signature",
"timestamp": 16775774797462,
"method": "private/get-open-orders",
"params": {
"symbol": "BTC-IDR",
"page": 0,
"page_size":50,
"side":"BUY"
}
}
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/get-open-orders",
"params": {
"symbol": "BTC-IDR",
"page": 0,
"page_size": 50,
"side":"BUY"
}
}

Request Parameters

Field Type Required Description
symbol string no symbol for which all currently opened orders should be returned
page integer yes page number (starts from zero)
page_size integer yes size of a page (default: 20, max: 200)
side string no side of order [BUY, SELL]

Response Parameters - The data payload containes the following fields:

Field Type Description
data.orders 2d-array (object) statuses of the orders that were found successfully. See below section for single order status definition
data.count integer number of the open orders found at the moment of the initial (page:0) inquiry submission

Response Parameters - Single order status defition contains the following fields:

Field Type Description
status string(enum) current order status: PLACED, CANCELED, REJECTED, PARTIALLY_FILLED, FILLED
reason string (optional) only sent for REJECTED order, actual rejection reason as string
symbol string instrument the order is placed for, ex. ‘BTC-IDR’
type string(enum) order type: MARKET, LIMIT
time_in_force string(enum) order validity instructions:
* for Market Orders - empty
* for Limit Orders - IOC (immediate-or-cancel) or FOK (fill-or-kill) or GTC (good-till-cancel)
exec_inst string(enum) (for Limit Orders only) - empty or POST_ONLY
side string(enum) BUY or SELL
price string price at which the order was placed. (Limit Order only)
size string original order quantity
cum_price string average price of already filled qty for this order (in case of the partial fill)
cum_size string cumulative filled quantity for this order (in case of the partial fill)
cum_value string cumulative filled quantity in QUOTE currency for this order (in case of the partial fill), ex. for ‘BTC-IDR’ the value will be in IDR
order_id string order id assigned by the Exchange
client_order_id string (optional) client id if assigned by the client while placing the order
created_at integer timestamp(unix milli) of order creation within Exchange
updated_at integer timestamp(unix milli) of the latest update of this order

Get Order History

Success response example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 16775774798300,
  "method": "private/get-order-history",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "orders": [
      {
        "status": "PARTIALLY_FILLED",
        "symbol": "BTC-IDR",
        "type": "LIMIT",
        "time_in_force": "GTC",
        "exec_inst": "POST_ONLY",
        "side": "BUY",
        "price": "15000",
        "size": "2",
        "cum_price": "15000",
        "cum_size": "0.35",
        "cum_value": "5250",
        "order_id": "12345678-abcd-efgh-ijkl-1234567890ab",
        "client_order_id": "my-order-id-1",
        "created_at": 16775774795300,
        "updated_at": 16775774797678
      },
      ...
    ]
  }
}

Error response example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 16775774798300,
  "method": "private/get-order-history",
  "code": 7,
  "message": "ORDER_NOT_FOUND",
  "reason": "Order not found"
}

Retrieve orders that have been placed previously by the client.

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/get-order-history
Page and page_size fields usage
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-key",
"signature": "my-signature",
"method": "private/get-order-history",
"params": {
"symbol": "BTC-IDR",
"t_start": 1676869976772,
"t_end": 1677869976772,
"page": 0,
"page_size": 50,
"status": "FILLED",
"side": "BUY"
}
}
Order_ids field usage
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-key",
"signature": "my-signature",
"method": "private/get-order-history",
"params": {
"symbol": "BTC-IDR",
"order_ids": [
"aaa-bbb-ccc",
...
],
"t_start": 1676869976772,
"t_end": 1677869976772,
}
}
Websocket Page and page_size fields usage
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/get-order-history",
"params": {
"symbol": "BTC-IDR",
"t_start": 1676869976772,
"t_end": 1677869976772,
"page": 0,
"page_size": 50,
"status": "FILLED",
"side": "BUY"
}
}
Order_ids field usage
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/get-order-history",
"params": {
"symbol": "BTC-IDR",
"client_order_ids": [
"xxx-yyy-zzz",
...
],
"t_start": 1676869976772,
"t_end": 1677869976772,
}
}

Request Parameters

Field Type Required Description
symbol string no Symbol name (example: BTC-IDR, ETH-IDR, etc.)
t_start integer yes start timestamp(unix milli) - defaults to 24 hours ago if empty (Only support 1 day range)
t_end integer yes end timestamp(unix milli) - defaults to now if empty (Only support 1 day range)
page integer no page number (starts from zero) NOTE: if order_ids are set, page value will be omitted
page_size integer no size of a page (default: 20, max: 200) NOTE: only used in case page field is set
side string(enum) no side of order [BUY, SELL]
status string(enum) no current order status: PLACED, CANCELED, REJECTED, PARTIALLY_FILLED, FILLED

Response Parameters - The data payload containes the following fields:

Field Type Description
data.orders 2d-array (object) statuses of the orders that were found successfully. See below section for single order status definition

Response Parameters - Single order status definition contains the following fields:

Field Type Description
status string(enum) current order status: PLACED, CANCELED, REJECTED, PARTIALLY_FILLED, FILLED
reason string (optional) only sent for REJECTED order, actual rejection reason as string
symbol string instrument the order is placed for, ex. ‘BTC-IDR’
type string(enum) order type: MARKET, LIMIT
time_in_force string(enum) order validity instructions:
* for Market Orders - empty
* for Limit Orders - IOC (immediate-or-cancel) or FOK (fill-or-kill) or GTC (good-till-cancel)
exec_inst string(enum) (for Limit Orders only) - empty or POST_ONLY
side string(enum) BUY or SELL
price string price at which the order was placed. (Limit Order only)
size string original order quantity
cum_price string average price of already filled qty for this order (in case of the partial fill)
cum_size string cumulative filled quantity for this order (in case of the partial fill)
cum_value string cumulative filled quantity in QUOTE currency for this order (in case of the partial fill), ex. for ‘BTC-IDR’ the value will be in IDR
order_id string order id assigned by the Exchange
client_order_id string (optional) client id if assigned by the client while placing the order
created_at integer timestamp(unix milli) of order creation within Exchange
updated_at integer timestamp(unix milli) of the latest update of this order

Get Order Details

Success response example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 16775774798300,
  "method": "private/get-order-details",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "order_info": {
      "status": "PARTIALLY_FILLED",
      "symbol": "BTC-IDR",
      "type": "LIMIT"
      "time_in_force": "GTC",
      "exec_inst": "POST_ONLY",
      "side": "BUY",
      "price": "15000",
      "size": "2",
      "cum_price": "15000",
      "cum_size": "0.35",
      "cum_value": "5250",
      "order_id": "12345678-abcd-efgh-ijkl-1234567890ab",
      "client_order_id": "my-cool-order-id-1",
      "created_at": 16775774795300,
      "updated_at": 16775774797678
    },
    "trades_info": [
      {
        "trade_id": "fake-trade-id-1",
        "symbol": "BTC-IDR",
        "side": "buy",
        "price": "15000",
        "fee": "0.001",
        "fee_asset": "BTC",
        "fee_type": "maker",
        "traded_size": "0.905",
        "traded_at": 16775774795500
      },
      {
        "trade_id": "fake-trade-id-2",
        "symbol": "BTC-IDR",
        "side": "buy",
        "price": "15000",
        "fee": "0.001",
        "fee_asset": "BTC",
        "fee_type": "maker",
        "traded_size": "0.755",
        "traded_at": 16775774795550
      }
    ]
  }
}

Error response example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 16775774798300,
  "method": "private/get-order-details",
  "code": 7,
  "message": "ORDER_NOT_FOUND",
  "reason": "Order not found"
}

Specific request that retrieves the full detail of the order that was placed by the client. Result reports the order status and, if any, trades that order took part in.

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/get-order-details
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-key",
"signature": "my-signature",
"method": "private/get-order-details",
"params": {
"symbol": "BTC-IDR",
"order_id": "aaa-bbb-ccc",
"t_start": 1676869976772,
"t_end": 1677869976772,
}
}
Websocket {
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/get-order-details",
"params": {
"symbol": "BTC-IDR",
"order_id": "xxx-yyy-zzz",
"t_start": 1676869976772,
"t_end": 1677869976772,
}
}

Request Parameters

Field Type Required Description
symbol string yes Symbol name (example: BTC-IDR, ETH-IDR, etc.)
order_id string required if client_order_id is empty exchange assigned order id
client_order_id string required if order_id is empty client order id
t_start integer yes start timestamp (Only support 1 day range) - unix milli
t_end integer yes end timestamp (Only support 1 day range) - unix milli

Response Parameters - The data payload containes the following fields:

Field Type Description
data.order_info object details of the orders that were found successfully. See below section for single order details definition
data.trades_info 2d-array (object) NOTE: only returned in case there were trades done for this order, empty array otherwise

Response Parameters - Trades Information array element is a simplified version of the detailed Trade information:

Field Type Description
side string(enum) side of order [BUY, SELL]
symbol string Symbol name (example: BTC-IDR, ETH-IDR, etc.)
fee string fee related to the trade
NOTE: value can be negative in case it’s a rebate
fee_asset string asset of what the deducted fee is based in, consisting either base or quote (example: BTC, IDR, etc.)
fee_type string(enum) source of the fee application [maker, taker]
trade_id string ID of a trade that is generated by Exchange
price string price where order wants to be placed
traded_size string amount in base that has been executed/filled
traded_at integer timestamp(unix milli) of when trade happened

Get Trade History

Success response example

Copy to Clipboard
{
    "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
    "timestamp": 16775774797463,
    "method": "private/get-trade-history",
    "code": "0",
    "message": "SUCCESS",
    "data": {
        "trades": [
            {
                "trade_id": "my-trade-id",
                "order_id": "my-order-id",
                "symbol": "BTC-IDR",
                "side": "buy",
                "price": "350000000",
                "fee": "0.001",
                "fee_asset": "BTC",
                "fee_type": "maker",
                "client_order_id": "my-client-order-id",
                "traded_size": "0.905",
                "traded_at": 1676869976772
            },
            ...
        ]
    }
}

Retrieves the full Private Trades information for the specific client’s account.

HTTP & Websocket Request

Protocol Body
HTTP POST /v1/private/get-trade-history
Page and page_size fields usage
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-key",
"signature": "my-signature",
"method": "private/get-trade-history",
"params": {
"symbol": "BTC-IDR",
"t_start": 16775773797462,
"t_end": 16775774797462,
"page": 0,
"page_size": 50
}
}
Trade_ids field usage
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-key",
"signature": "my-signature",
"method": "private/get-trade-history",
"params": {
"trade_ids": [
"a88b9054-bde2-4fd7-8a4e-c6ff6de61138",
"a88b9054-bde2-4fd7-8a4e-c6ff6de61139",
...
],
"symbol": "BTC-IDR",
"t_start": 16775773797462,
"t_end": 16775774797462,
}
}
Websocket Page and page_size fields usage
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/get-trade-history",
"params": {
"symbol": "BTC-IDR",
"t_start": 16775773797462,
"t_end": 16775774797462,
"page": 0,
"page_size": 50
}
}
Trade_ids field usage
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "private/get-trade-history",
"params": {
"trade_ids": [
"a88b9054-bde2-4fd7-8a4e-c6ff6de61138",
"a88b9054-bde2-4fd7-8a4e-c6ff6de61139",
...
],
"symbol": "BTC-IDR",
"t_start": 16775773797462,
"t_end": 16775774797462,
}
}

Request Parameters

Field Type Required Description
params.symbol string no Symbol name (example: BTC-IDR, ETH-IDR, etc.)
params.trade_ids array of strings depends Identifier of a trade, max size 200
NOTE: omitted in case page field is used
params.t_start integer yes Start timestamp(unix milli) - defaults to 24 hours ago if empty (Only support 1 day range)
params.t_end integer yes End timestamp(unix milli) - defaults to now if empty (Only support 1 day range)
params.page integer depends page number (starts from zero) NOTE: if trade_ids are set, page value will be omitted
params.page_size integer depends size of a page (default: 20, max: 200) NOTE: only used in case page field is set

Response Parameters - Single trade definition contains the following fields:

Field Type Description
trades.[index].trade_id string ID of a trade that is generated by Exchange
trades.[index].order_id string ID of an order that is generated by Exchange
trades.[index].symbol string Symbol name (example: BTC-IDR, ETH-IDR, etc.)
trades.[index].side string(enum) side of order [BUY, SELL]
trades.[index].price string price where order wants to be placed
trades.[index].traded_size string amount in base that has been executed/filled
trades.[index].fee string fee related to the trade
NOTE: value can be negative in case it’s a rebate
trades.[index].fee_asset string asset of what the deducted fee is based in, consisting either base or quote (example: BTC, IDR, etc.)
trades.[index].fee_type string(enum) source of the fee application [maker, taker]
trades.[index].client_order_id string unique key that will be used by clients to identify their orders
trades.[index].traded_at integer timestamp(unix milli) of when trade happened

Fund Management API

Create Withdrawal

Example request

Copy to Clipboard
{
    "api_key": "es3jfk6RccWzuJBd",
    "method": "private/create-withdrawal",
    "params": {
        "amount": "420",
        "asset": "USDT",
        "full_name": "Bartholomew Bumblefizz III",
        "network": "Binance Smartchain",
        "residential_address": "The Teapot Cottage, 7 ½ Mushroom Lane, Willowbrook Glade,  Gnomeville,  Middle-earth",
        "to_address": "0x919dcAbb830AEc5F63599A3165f89862819601F0",
        "to_memo": ""
    },
    "request_id": "dec3b2d8-02e8-4acb-8a13-f1e7f07d069e",
    "signature": "a5a4e0412d3b11882f02fc1c1c3922197663047a600805797253961354f969a3",
    "timestamp": 1739352304101
}

Success response example

Copy to Clipboard
{
  "request_id": "dec3b2d8-02e8-4acb-8a13-f1e7f07d069e",
  "timestamp": 1739352304102,
  "method": "private/create-withdrawal",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "withdrawal_id": "ec617015-fc8e-4445-9aa9-5785dae507d4",
  }
}

Create withdrawal endpoint initiates a process of withdrawing funds to blockchain address. Successful response means request has passed the validation and corresponding amount is locked for withdrawal. Withdrawal will be processed asynchronously and its status can be checked using /v1/private/get-withdrawal-status endpoint.

HTTP Request

HTTP POST /v1/private/create-withdrawal

Request Parameters

Field Type Required Description
to_address string yes Address of user’s wallet
to_memo string no Memo of the transaction
asset string (enum) yes Type of asset user want to withdraw
network string (enum) yes Network of the transaction
amount string yes Amount of asset user want to withdraw
full_name string depends Full name of the recipient of funds
residential_address string depends Residential address of the recipient of funds
travel_rule_id string depends Identifier of a pre-populated travel rule record

Either travel_rule_id or full_name and residential_address are required to comply with the FATF travel rule regulation. Value for travel_rule_id can be provided by your Pintu manager.

Response Parameters

Field Type Description
withdraw_id string ID generated by Exchange. User will use this withdraw_id to check the status of the withdrawal

Confirm withdrawal

Request with TOTP code

Copy to Clipboard
{
  "request_id":"a88b9054-bde2-4fd7-8a4e-c6ff6de212a6",
  "api_key":"HnJYkI8PagKoJz1V",
  "signature":"00bb10504a795f10baa64afa63589c1b1ff3cb1416c083ea328e05860eee7970",
  "method":"private/confirm-withdrawal",
  "params":{
    "withdrawal_id":"04e2e210-3718-44bd-95d5-fc336cd77e58",
    "authenticator_code":"778899",
    },
  "timestamp":1738828851868
}

Success response

Copy to Clipboard
{
    "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212a6",
    "timestamp": 1738828854168,
    "method": "private/confirm-withdrawal",
    "code": 0,
    "message": "SUCCESS",
    "data": {
        "withdrawal_id": "04e2e210-3718-44bd-95d5-fc336cd77e58",
        "message": "SUCCESS"
    }
}

Depending on user's security settings withdrawal may require OTP confirmation. OTP can be sent to user's email or phone number, or time-based OTP (such as Google Authenticator) can be used.

HTTP Request

HTTP POST /v1/private/confirm-withdrawal

Request Parameters

Field Type Required Description
withdrawal_id string yes Identifier of withdrawal to confirm
authenticator_code string depends TOTP authenticator code
otp_code string depends OTP code (delivered via SMS/Email)

Either authenticator_code or otp_code is required.

Response Parameters

Field Type Description
withdrawal_id string Will return id of the confirmed withdrawal.

Get Funds Transfer History

Success response example

Copy to Clipboard
{
  "request_id": "aqab9054-1111-1111-1111-c6ff6de332e5",
  "timestamp": 1694595911,
  "method": "private/get-funds-transfer-history",
  "code": 0,
  "message": "SUCCESS",
  "data": {
  "deposits": [
      {
      "amount": "20000",
      "asset": "IDR",
      "type": "DEPOSIT",
      "created_at": 1694511704030,
      "transact_at": 1694511703615,
      "hash": "321987s49hks93812sdf",
      "from_address": "",
      "to_address": "czx41237cad321da312",
      "memo": "",
      "network": "Ethereum",
      "status": "SUCCESS"
      }
    ],
    "withdrawals": [
      {
      "amount": "10000",
      "asset": "IDR",
      "fee": "",
      "withdrawal_id": "321321a-2222-1111-2222-91212134d47",
      "created_at": 1694513832263,
      "transact_at": 1694519845526,
      "hash": "",
      "from_address": "",
      "to_address": "",
      "to_memo": "",
      "network": "",
      "status": "SUCCESS"
      }
    ]
  }
}

HTTP Request

Protocol Body
HTTP POST /v1/private/get-funds-transfer-history
{
"request_id": "aqab9054-bde2-4fd7-8a4e-c6ff11e212e5",
"api_key": "my-key",
"signature": "my-signature",
"method": "private/get-funds-transfer-history",
"params": {
"status":"SUCCESS",
"type":"WITHDRAWAL, DEPOSIT",
"page":1,
"page_size":"20,
"from": 1676869976772,
"to": 1677869976772
}
}

Request Parameters

Field Type Required Description
type string (enum) yes type of transaction, DEPOSIT or WITHDRAWAL
status string (enum) yes status of the fund. INIT, SUCCESS, FAILED - will return all if empty
page int no page number (starts from zero)
page_size timestamp yes size of a page (default: 20, max: 200)
from timestamp yes start timestamp (unix milli) - defaults to 24 hours ago if empty (Only support 1 day range)
to timestamp yes end timestamp (unit milli) - defaults to now if empty (Only support 1 day range)

Response Parameters

Field Type Description
deposits array of object Array of deposits
withdrawals array of object Array of withdrawals

Response Parameters - deposits

Field Type Description
amount string Amount of the transaction
asset string Asset of the transaction
type string (enum) Type of deposit
created_at timestamp Timestamp of the transaction in exchange (unix milli)
transact_at timestamp Timestamp of the transaction on chain (unix milli)
hash string Hash of the transaction
from_address string From address of the transaction (For internal transaction address will be Pintu Pro or something else)
to_address string To address of the transaction
memo string Memo of the transaction
network string (enum) Network of the deposit taken place
status string (enum) status of the request. SUCCESS, FAILED

Response Parameters - withdrawals

Field Type Description
amount string Amount of the withdrawal request
asset string (enum) Asset of the transaction
fee string Fee of the withdrawal transaction
withdrawal_id string ID generated by Exchange. User will use this withdraw_id to check the status of the withdrawal
created_at timestamp Timestamp of the request (unix milli)
transact_at timestamp Timestamp of the transaction on chain (unix milli)
hash string Hash of the transaction
from_address string Address of the receiver’s wallet
to_address string Address of the user’s wallet
to_memo string Memo of the transaction
network string (enum) Network of the deposit taken place
status string (enum) status of the request. INIT, SUCCESS, FAILED

Get Withdrawal Status

Success response example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-1111-2222-c6ff6de212e1",
  "timestamp": 1694596244,
  "method": "private/get-withdrawal-status",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "amount": "0.0001",
    "fee": "0.000005",
    "withdraw_id": "5630a62e-6c89-2222-1111-6b5087dde0e9",
    "created_at": 1694596165484,
    "updated_at": 1694596166128,
    "transact_at": 0,
    "to_address": "3123123123asdasdasdas312312",
    "to_memo": "",
    "status": "INIT"
  }
}

HTTP Request

Protocol Body
HTTP POST /v1/private/get-withdrawal-status
{
"request_id": "a88b9054-2222-3333-1111-c6ff6de212e2",
"api_key": "my-api-key",
"signature": "my-signature",
"timestamp": 16775774797462
"method": "private/get-withdrawal-status",
"params": {
"withdraw_id": "b751483e-1111-2222-1111-fe8889954d59"
}
}

Request Parameters

Field Type Description
withdraw_id string ID generated by Exchange. User will use this withdraw_id to check the status of the withdrawal

Response Parameters

Field Type Description
amount string Amount of the withdrawal request
fee string Fee of the withdrawal transaction
withdraw_id string ID generated by Exchange. User will use this withdraw_id to check the status of the withdrawal
created_at timestamp Timestamp of the request
updated_at timestamp ID generated by Exchange. User will use this withdraw_id to check the status of the withdrawal
transact_at timestamp Transaction of the withdrawal happen on chain
to_address string Address of the user’s wallet
to_memo string Memo of the transaction
status string (enum) status of the withdrawal: INIT,SUCCESS,FAILED

Get Deposit Addresses

Success response example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-2222-1111-c6ff6de212e4",
  "timestamp": 1691631580,
  "method": "private/get-deposit-addresses",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "deposit_addresses": [
      {
        "address": "3123123dasdasda32131212",
        "asset": "BTC",
        "memo": "user_memo",
        "network": "Bitcoin"
      }
    ]
  }
}

HTTP Request

Protocol Body
HTTP POST /private/get-deposit-addresses
{
"request_id": "a88b9054-2222-1111-3333-c6ff6de212e4",
"api_key": "my-api-key",
"signature": "my-signature",
"method":"private/get-deposit-addresses",
"params": {
"asset": "BTC"
}
}

Request Parameters

Field Type Required Description
asset string (enum) yes Type of asset. Will return all if empty

Response Parameters

Field Type Description
addresses array of object Array of deposit addresses

Response Parameters - Each address contains:

Field Type Description
address string Address to deposit
asset string (enum) Type of asset user want to deposit
memo string Memo of the address
network string (enum) Network of the address

Get Network Reference

Success response example

Copy to Clipboard
{
  "timestamp": 1694595267,
  "method": "public/get-network-reference",
  "code": 0,
  "message": "SUCCESS",
  "data": {
    "networks": [
      {
        "asset": "BTC",
        "name": "Bitcoin",
        "fee": "0.0005"
      }
    ]
  }
}

HTTP Request

Protocol Body
HTTP GET /v1/public/get-network-reference?asset=BTC

Request Parameters

Field Type Required Description
asset string (enum) yes Type of asset

Response Parameters

Field Type Description
networks array of object list of networks in the dictionary. The keys of the dictionary is the token name such as IDR, SOL, BTC, and ETH

Response Parameters - Each network contains:

Field Type Description
name string (enum) Name of the network
asset string (enum) Type of asset
fee string Withdrawal fee

Private Websocket Subscriptions

User Balance Snapshot

Stream data record example

Copy to Clipboard
{
"timestamp": 1676869976772,
"method": "subscription",
"channel": "user.balance.snapshot",
"data": {
  "assets": {
    "btc": {
      "balance": "10",
      "available": "8",
      "order": "2"
    },
    "eth": {
      "balance": "32",
      "available": "30",
      "order": "2",
    },
    ...
    }
  }
}

Channel: user.balance

{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "subscribe",
"params": {
"channels": ["user.balance.snapshot"]
}
}

Streaming Reply - Channel update contains the following fields:

Field Type Description
assets object List of all non-zero assets in the wallet in dictionaries. The keys of the dict is the asset name such as "eth", "btc"
assets.[asset_name].balance string Total balance of current asset
assets.[asset_name].available string Available amount to withdraw of current asset
assets.[asset_name].order string Total asset currently in open order

User Orders per symbol

Stream data record example

Copy to Clipboard
{
"timestamp": 1676869976772,
"method": "subscription",
"channel": "user.orders.BTC-IDR",
"data": {
  "orders": [
    {
      "status": "PARTIALLY_FILLED",
      "symbol": "BTC-IDR",
      "type": "LIMIT"
      "time_in_force": "GTC",
      "exec_inst": "POST_ONLY",
      "side": "BUY",
      "price": "15000",
      "size": "2",
      "cum_price": "15000",
      "cum_size": "0.35",
      "cum_value": "5250",
      "order_id": "12345678-abcd-efgh-ijkl-1234567890ab",
      "client_order_id": "my-cool-order-id-1",
      "created_at": 16775774795300,
      "updated_at": 16775774797678
    },
      ...
    ]
  }
}

Unsubscribe response example (in case of multiple channels)

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 1676869976772,
  "method": "unsubscribe",
  "code": "OK",
  "message": "Success",
  "data": {
    "channel": "user.orders.BTC-IDR"
  }
}

{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 1676869976775,
  "method": "unsubscribe",
  "code": "OK",
  "message": "Success",
  "data": {
    "channel": "user.orders.ETH-IDR",
  }
}

This is a private API, which requires authorization fields to be provided on the body. See this page for reference.

Channel: user.orders.{symbol}

{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-api-key",
"signature": "my-signature",
"method": "subscribe", // subscribe
"params": {
"channels": [
"user.orders.BTC-IDR",
...
]
}
}

Unsubscription Request
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-api-key",
"signature": "my-signature",
"method": "unsubscribe", // unsubscribe
"params": {
"channels": [
"user.orders.BTC-IDR",
"user.orders.ETH-IDR",
...
]
}
}

NOTE: in case unsubscribe request contains multiple channels in it’s payload, the client should expect one response message per channel in return

Streaming Reply - Channel update contains the following fields:

Field Type Description
data.orders 2d-array (object) statuses of the orders that were found successfully. See below section for single order status definition

Streaming Reply - Single order status definition contains the following fields:

Field Type Description
status string(enum) current order status: PLACED, CANCELED, REJECTED, PARTIALLY_FILLED, FILLED
reason string (optional) only sent for REJECTED order, actual rejection reason as string
symbol string instrument the order is placed for, ex. ‘BTC-IDR’
type string(enum) order type: MARKET, LIMIT
time_in_force string(enum) order validity instructions:
* for Market Orders - empty
* for Limit Orders - IOC (immediate-or-cancel) or FOK (fill-or-kill) or GTC (good-till-cancel)
exec_inst string(enum) (for Limit Orders only) - empty or POST_ONLY
side string(enum) BUY or SELL
price string price at which the order was placed. (Limit Order only)
size string original order quantity
cum_price string average price of already filled qty for this order (in case of the partial fill)
cum_size string cumulative filled quantity for this order (in case of the partial fill)
cum_value string cumulative filled quantity in QUOTE currency for this order (in case of the partial fill), ex. for ‘BTC-IDR’ the value will be in IDR
order_id string order id assigned by the Exchange
client_order_id string (optional) client id if assigned by the client while placing the order
created_at integer timestamp(unix milli) of order creation within Exchange
updated_at integer timestamp(unix milli) of the latest update of this order

User Orders (all symbols)

Stream data record example

Copy to Clipboard
{
"timestamp": 1676869976772,
"method": "subscription",
"channel": "user.orders",
"data": {
  "orders": [
    {
      "status": "PARTIALLY_FILLED",
      "symbol": "BTC-IDR",
      "type": "LIMIT"
      "time_in_force": "GTC",
      "exec_inst": "POST_ONLY",
      "side": "BUY",
      "price": "15000",
      "size": "2",
      "cum_price": "15000",
      "cum_size": "0.35",
      "cum_value": "5250",
      "order_id": "12345678-abcd-efgh-ijkl-1234567890ab",
      "client_order_id": "my-cool-order-id-1",
      "created_at": 16775774795300,
      "updated_at": 16775774797678
    },
      ...
    ]
  }
}

Unsubscribe response example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 1676869976772,
  "method": "unsubscribe",
  "code": "OK",
  "message": "Success",
  "data": {
    "channel": "user.orders"
  }
}

This is a private API, which requires authorization fields to be provided on the body. See this page for reference.

Channel: user.orders

{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-api-key",
"signature": "my-signature",
"method": "subscribe", // subscribe
"params": {
"channels": [
"user.orders",
...
]
}
}

Unsubscription Request
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-api-key",
"signature": "my-signature",
"method": "unsubscribe", // unsubscribe
"params": {
"channels": [
"user.orders",
"user.orders.ETH-IDR",
...
]
}
}

NOTE: in case unsubscribe request contains multiple channels in it’s payload, the client should expect one response message per channel in return

Streaming Reply - Channel update contains the following fields:

Field Type Description
data.orders 2d-array (object) statuses of the orders that were found successfully. See below section for single order status definition

Streaming Reply - Single order status definition contains the following fields:

Field Type Description
status string(enum) current order status: PLACED, CANCELED, REJECTED, PARTIALLY_FILLED, FILLED
reason string (optional) only sent for REJECTED order, actual rejection reason as string
symbol string instrument the order is placed for, ex. ‘BTC-IDR’
type string(enum) order type: MARKET, LIMIT
time_in_force string(enum) order validity instructions:
* for Market Orders - empty
* for Limit Orders - IOC (immediate-or-cancel) or FOK (fill-or-kill) or GTC (good-till-cancel)
exec_inst string(enum) (for Limit Orders only) - empty or POST_ONLY
side string(enum) BUY or SELL
price string price at which the order was placed. (Limit Order only)
size string original order quantity
cum_price string average price of already filled qty for this order (in case of the partial fill)
cum_size string cumulative filled quantity for this order (in case of the partial fill)
cum_value string cumulative filled quantity in QUOTE currency for this order (in case of the partial fill), ex. for ‘BTC-IDR’ the value will be in IDR
order_id string order id assigned by the Exchange
client_order_id string (optional) client id if assigned by the client while placing the order
created_at integer timestamp(unix milli) of order creation within Exchange
updated_at integer timestamp(unix milli) of the latest update of this order

User Trades per symbol

Stream data record example

Copy to Clipboard
{
  "timestamp": 1672304484978,
  "method": "subscription",
  "channel": "user.trades.BTC-IDR",
  "data": {
    "trades": [
      {
      "trade_id": "fake-trade-id-2",
      "order_id": "aaa-bbb-ccc-2",
      "symbol": "BTC-IDR",
      "side": "buy",
      "price": "351000000",
      "fee": "0.001",
      "fee_asset": "BTC",
      "fee_type": "maker",
      "traded_size": "0.105",
      "client_order_id": "xxx-yyy-zzz-2",
      "traded_at": 1676869976772
      },
      ...
      {
      "trade_id": "fake-trade-id-1",
      "order_id": "aaa-bbb-ccc-1",
      "symbol": "BTC-IDR",
      "side": "buy",
      "price": "350000000",
      "fee": "0.001",
      "fee_asset": "BTC",
      "fee_type": "maker",
      "traded_size": "0.905",
      "client_order_id": "xxx-yyy-zzz-1",
      "traded_at": 1676869976760
      }
    ]
  }
}

Unsubscribe response example (in case of multiple channels)

Copy to Clipboard
{
    "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
    "timestamp": 1676869976772,
    "method": "unsubscribe",
    "code": "OK",
    "message": "Success",
    "data": {
            "channel": "user.trades.BTC-IDR"
    }
}

{
    "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
    "timestamp": 1676869976775,
    "method": "unsubscribe",
    "code": "OK",
    "message": "Success",
    "data": {
            "channel": "user.trades.ETH-IDR",
    }
}

This is a private API, which requires authorization fields to be provided on the body. See this page for reference.

NOTE: the order of the elements in the trades array is by traded_at field, where most recent message comes first. This way some parsing level optimizations (re reaction time) can be possible on the client side.

Channel: user.trades.{symbol}

{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-api-key",
"signature": "my-signature",
"method": "subscribe", // subscribe
"params": {
"channels": [
"user.trades.BTC-IDR",
...
]
}
}

Unsubscription Request
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-api-key",
"signature": "my-signature",
"method": "unsubscribe", // unsubscribe
"params": {
"channels": [
"user.trades.BTC-IDR",
"user.trades.ETH-IDR",
...
]
}
}

NOTE: in case unsubscribe request contains multiple channels in it’s payload, the client should expect one response message per channel in return.

Streaming Reply - Channel update contains the following fields:

Field Type Description
data.trades array Updates on trades happened since last message

Streaming Reply - Single trade definition contains the following fields:

Field Type Description
trades.[index].trade_id string ID of a trade that is generated by Exchange
trades.[index].order_id string ID of an order that is generated by Exchange
trades.[index].symbol string Symbol name (example: BTC-IDR, ETH-IDR, etc.)
trades.[index].side string(enum) side of order [BUY, SELL]
trades.[index].price string price where order wants to be placed
trades.[index].traded_size string amount in base that has been executed/filled
trades.[index].fee string fee related to the trade
NOTE: value can be negative in case it’s a rebate
trades.[index].fee_asset string asset of what the deducted fee is based in, consisting either base or quote (example: BTC, IDR, etc.)
trades.[index].fee_type string(enum) source of the fee application [maker, taker]
trades.[index].client_order_id string unique key that will be used by clients to identify their orders
trades.[index].traded_at integer timestamp(unix milli) of when trade happened

User Trades (all symbols)

Stream data record example

Copy to Clipboard
{
  "timestamp": 1672304484978,
  "method": "subscription",
  "channel": "user.trades",
  "data": {
    "trades": [
      {
      "trade_id": "fake-trade-id-2",
      "order_id": "aaa-bbb-ccc-2",
      "symbol": "BTC-IDR",
      "side": "buy",
      "price": "351000000",
      "fee": "0.001",
      "fee_asset": "BTC",
      "fee_type": "maker",
      "traded_size": "0.105",
      "client_order_id": "xxx-yyy-zzz-2",
      "traded_at": 1676869976772
      },
      ...
      {
      "trade_id": "fake-trade-id-1",
      "order_id": "aaa-bbb-ccc-1",
      "symbol": "SOL-IDR",
      "side": "buy",
      "price": "350000000",
      "fee": "0.001",
      "fee_asset": "SOL",
      "fee_type": "maker",
      "traded_size": "0.905",
      "client_order_id": "xxx-yyy-zzz-1",
      "traded_at": 1676869976760
      }
    ]
  }
}

Unsubscribe response example

Copy to Clipboard
{
    "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
    "timestamp": 1676869976772,
    "method": "unsubscribe",
    "code": "OK",
    "message": "Success",
    "data": {
            "channel": "user.trades"
    }
}

This is a private API, which requires authorization fields to be provided on the body. See this page for reference.

NOTE: the order of the elements in the trades array is by traded_at field, where most recent message comes first. This way some parsing level optimizations (re reaction time) can be possible on the client side.

Channel: user.trades.{symbol}

{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-api-key",
"signature": "my-signature",
"method": "subscribe", // subscribe
"params": {
"channels": [
"user.trades,
...
]
}
}

Unsubscription Request
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-api-key",
"signature": "my-signature",
"method": "unsubscribe", // unsubscribe
"params": {
"channels": [
"user.trades",
"user.trades.ETH-IDR",
...
]
}
}

NOTE: in case unsubscribe request contains multiple channels in it’s payload, the client should expect one response message per channel in return.

Streaming Reply - Channel update contains the following fields:

Field Type Description
data.trades array Updates on trades happened since last message

Streaming Reply - Single trade definition contains the following fields:

Field Type Description
trades.[index].trade_id string ID of a trade that is generated by Exchange
trades.[index].order_id string ID of an order that is generated by Exchange
trades.[index].symbol string Symbol name (example: BTC-IDR, ETH-IDR, etc.)
trades.[index].side string(enum) side of order [BUY, SELL]
trades.[index].price string price where order wants to be placed
trades.[index].traded_size string amount in base that has been executed/filled
trades.[index].fee string fee related to the trade
NOTE: value can be negative in case it’s a rebate
trades.[index].fee_asset string asset of what the deducted fee is based in, consisting either base or quote (example: BTC, IDR, etc.)
trades.[index].fee_type string(enum) source of the fee application [maker, taker]
trades.[index].client_order_id string unique key that will be used by clients to identify their orders
trades.[index].traded_at integer timestamp(unix milli) of when trade happened

Public Websocket Subscriptions

Orderbook Snapshot

Stream data record example

Copy to Clipboard
{
  "request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
  "timestamp": 1672304484978,
  "method": "subscription",
  "channel": "aggrbook.snapshot.10.BTC-USDT",
  "data": {
    "symbol": "BTC-USDT",
    "bids": [
        ...,
        [
    "16493.50",
    "0.006",
    "100",
        ],
        [
    "16493.00",
    "0.100",
    "87",
        ]
    ],
    "asks": [
        [
    "16611.00",
    "0.029",
    "124",
        ],
        [
    "16612.00",
    "0.213",
    "90",
        ],
        ...,
    ]
  }
}

Channel: aggrbook.snapshot.{depth}.{symbol}


{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "subscribe",
"params": {
"channels": ["aggrbook.snapshot.{depth}.{symbol}"]
}
}

Request Parameters

Field Type Required Description
symbol string yes Symbol name
depth integer no The depth (number of price levels) of the market data book. Default is 1 for level 1 order book (quotes). Valid values are 1 or 10.

Streaming Reply - Channel update contains the following fields:

Field Type Description
data.symbol string Symbol name
data.bids array (string) Price levels ordered by descending by price. Each price level is three elements array of decimals. Bids array: [0] = Price, [1] = Quantity, [2] = Number of Orders
data.asks array (string) Price levels ordered by descending by price. Each price level is three elements array of decimals. Bids array: [0] = Price, [1] = Quantity, [2] = Number of Orders

Trades

Stream data record example

Copy to Clipboard
{
  "timestamp": 1672304484978,
  "method": "subscription",
  "channel": "trades.BTC-USDT",
  "data":
    "trades": [
      {
        "side": "SELL",
        "price": "51327.500000",
        "size": "0.000100",
        "timestamp": 1613581138462,
        "symbol": "BTC-USDT"
      }
    ]
  }
}

Channel: trades.{symbol}


{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"method": "subscribe",
"params": {
"channels": ["trades.{symbol}"]
}
}

Unsubscription Request
{
"request_id": "a88b9054-bde2-4fd7-8a4e-c6ff6de212e2",
"timestamp": 16775774797462,
"api_key": "my-api-key",
"signature": "my-signature",
"method": "unsubscribe", // unsubscribe
"params": {
"channels": [
"user.trades.BTC-IDR",
"user.trades.ETH-IDR",
...
]
}
}

Request Parameters

Field Type Required Description
symbol string yes Symbol name

Streaming Reply - Channel update contains the following fields:

Field Type Description
data.trades array Updates on trades happened since last message

Streaming Reply - Single trade definition contains the following fields:

Field Type Description
trades.[index].side string Side of the taker order (buy or sell)
trades.[index].price string Trade price
trades.[index].size string Trade quantity
trades.[index].timestamp integer Trade timestamp(unix milli)
trades.[index].symbol string Symbol name (example: BTC-IDR, ETH-IDR, etc.)
